Machine Description
We are pleased to offer:.
Used MAGNUM MCC-35ASP Year 2019.
Specification.
Automatic Business Card Cutter.
Easily exchangeable slide-in crease/perforate tools.
Create up to 32 cuts, creases and perforations in one pass.
High-speed job changeover with 64 preset programs.
Top vacuum feeding with central registration.
Ultrasonic double-feed detector.
High-volume waste bin.
Strike perf capabilities for “box” or “T” perforation.
Barcode reader allows multiple jobs to be stacked for auto-feeding.
Ideal for creasing menus, book covers, leaflets, business cards and invitations..
Infeed: Automatic.
Infeed Paper Spec(W*L): Max. 330mm× 650mm, Min. 210mm× 210mm.
Output Size(W*L): Max. 330mm× 650mm/ Min. 50mm× 48mm.
Paper Weight: 150-350gsm.
Paper Type: Chrome, Laminated, UV Coated, etc.
Cross Cutter:.
First Cut: 3.2-15mm,.
Last Cut: 5-15mm,.
Gutter Cut: 3-15mm,.
Min Card Size for Cutter: 48mm,.
Max. quality for Cutter per Sheet: 32,.
Accuracy for Cutting: ± 0.2-0.4mm.
Slit: Slitters: 6, Side Trim: 3.2-38mm, Gutter Slit: 0 or 5-15mm, Accuracy for Slitting: ± 0.3mm.
Max. quality for Crease per Sheet: 32.
Crease Depth Adjustment: 8 Level Auto Adjust.
Crease Direction: Both.
Crease Die Spec: 1.0mm.
Accuracy for Creasing: ± 0.3mm.
Feeding Type: Top Vacuum.
Speed (A4 trimming 4 sides, crease in the middle): 20Sheets/min.
Pile Loading: 100mm.
Double Feed Detect: Ultrasonic Detecting.
User Template Storage: 64.
Colour touchscreen display and control: 230 mm.
Dimensions Length*Width*Height: 1960 X 700 X 1200 mm.
Power Source: AC110V-240V,50/60Hz.
Power: 800W.
Weight: 150kg.
Good working order.
Available immediately.
Read more: https://www.jerrycurtin.com/machine/en-134478/magnum-mcc-35-asp...
The Magnum MCC 35 ASP is a high-performance automatic creasing machine designed for precision cutting, creasing, and perforating applications. Ideal for commercial printing and finishing operations, this 2019 model delivers exceptional versatility with its ability to create up to 32 cuts, creases, or perforations in a single pass. Key features include easily exchangeable slide-in crease/perforate tools, high-speed job changeover with 64 preset programs, and a top vacuum feeding system with central registration. The machine also incorporates an ultrasonic double-feed detector, barcode reader for automated job processing, and a high-volume waste bin. Perfect for producing business cards, menus, book covers, leaflets, and invitations, the MCC 35 ASP combines precision engineering with user-friendly operation, making it a valuable asset for high-volume finishing tasks.
Key Technical Aspects:
Dimensions and Specifications : The Magnum MCC 35 ASP has compact dimensions of 1960 mm (L) × 700 mm (W) × 1200 mm (H) and weighs 150 kg. It operates on a power supply of AC110V-240V, 50/60Hz with a power consumption of 800W. The machine features a 230 mm color touchscreen display for intuitive control and supports 64 user template storage programs. Maximum processing speed reaches 20 sheets per minute for A4 trimming with central creasing.
Paper Handling : This machine offers automatic top vacuum feeding with central registration and ultrasonic double-feed detection. It accommodates paper sizes from a minimum of 210 mm × 210 mm to a maximum of 330 mm × 650 mm, with output sizes ranging from 50 mm × 48 mm to 330 mm × 650 mm. The MCC 35 ASP handles paper weights between 150-350 gsm and supports various paper types including chrome, laminated, and UV-coated materials. The pile loading capacity is 100 mm, and the machine includes a high-volume waste bin for efficient production.
| Model | Magnum-MCC 35 ASP |
|---|---|
| Manufacturer | Magnum |
| Year | 2019 |
| Machine Availability | Immediately |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Ringwood, UK |
Special Features
- Max.Size: 65 x 33 cm (25 x 12 inch)
Magnum - MCC 35 ASP
