Automatic Non Woven box bag making with online handle attach with cooling box bag function
About Machine
Automatic Non Woven box bag making with online handle attach with cooling box bag function
Features
| Bag mouth auto adjustment |
| Handle auto center adjustment |
| Handle length auto change |
| Speed 80-90pcs/min(parts high precision) |
| Mould change time reduce to 30-50mins |
| Servo Motor-28PCS |
| Increase speed from 50pcs/min to 90pcs/min, wastage 0 |
| Tape running according to each bag size,wastage 0% |
Technical Specifications
| Roller width | 560-1160mm |
| Bag making speed | 80-90pcs/min |
| Bag width | 100-500mm |
| Bag Height | 180-450mm |
| Gusset | 80-220mm |
| Power supply | 380V |
| Total power | 55KW |
| Rated power | 20KW |
| Overall size | L 11000* W 4800* H 3100mm |
| Weight of Machine | 12500KGS (40HQ*1+20FT*1 ) |
| Handle Length | 370-550mm |
| Handle Width | 25mm &30mm |
| PP woven thickness | 80-140gsm |
| Non woven thickness | 80-140gsm |
