Four Color Printing Machine - BPL
Four Color Printing Machine - BPL
Four Color Printing Machine - BPL
Features
| Rigid construction & vibration free working. |
| All cylinders are hard chrome plated. |
| All cylinders are hard chrome plated. |
| DC drive |
| Drive gears precision ground for long life. |
| High quality printing with perfect registration. |
| Fine ink feed & controls for highly uniform ink |
| Centralised Lubrication System |
Technical Specifications
| Sheet Size (max) | 18.5”x25.5” |
| Sheet Size (min) | 9”x10” |
| Printing area (max) | 17.5”x25” |
| Gripper Margin on Paper | 9 mm |
| Gripper Margin on plate | 1.25" |
| Plate size | 20”x26” |
| Plate thickness | 0.2mm |
| Blanket size | 22”x26” |
| Pile height feeder | 32 |
| Pile height delivery | 16 |
| Paper thickness (gsm) | 30-450 |
| No. of inking rollers | 80 |
| No. of dampening rollers | 20 |
| No. of ink form rollers | 12 |
| Main drive motor | 10ph |
