Machine Specification
| Features | Value |
|---|---|
| Number of colours | 6 |
| Max sheet size | 29.5 x 41.3 inch | 75 x 105 cm |
Machine Description
Size: 75 x 106 cm, 18,000 SPH, Dedicated tower coater with x2 extended delivery, Prinect Axis Control integrated console with WallScreen , XY spectral adjustment from the console with Closed Loop, InkStar fully automated ink metering system with CAN connection to the console , CombiStar central re-circulation and refrigeration, DryStar IR drying module, Pre-Set Plus X2 Delivery extension - Non Stop, PowderStar AP500 anti offset system, Pre-Set Feeder - Non Stop with pull side lay and ultrasonic double sheet detection and pre-loader, CleanStar powder extraction system, StaticStar anti-static system in feeder & delivery with ionizer, Air Transfer sheet travel control system, Cardboard Kit sheet travel system, Autoplate Advanced, Auto Blanket and Auto Cylinder wash, Vario dampening, Chambered doctor blade Anilox Coater, AirStar Pro air cooled air supply cabinet, 45mio impression count.
| Model | Heidelberg-Speedmaster XL 106 |
|---|---|
| Manufacturer | Heidelberg |
| Year | 2015 |
| Machine Availability | Immediately |
| Machine Condition | Excellent |
| Price | 1100000.00 USD |
| Location | United States |
Special Features
- Autoplate
- Coating
- Computer Controls/ Digital Controls
About Heidelberg - Speedmaster XL 106
The Heidelberg Speedmaster XL 106 is a high-performance sheet-fed offset printing press designed for commercial and packaging printing applications. This machine is part of the Speedmaster XL series, known for its exceptional print quality, high productivity, and versatility. The Speedmaster XL 106 is ideal for printing a wide range of materials, including paper, board, and plastics, and is suitable for various industries, such as commercial printing, packaging, and label printing. Its key features include high-speed printing, precise registration, and advanced automation, making it an excellent choice for printers seeking to increase their production capacity and reduce turnaround times.
Key Technical Aspects:
Dimensions and Specifications : The Heidelberg Speedmaster XL 106 has a length of 23.62 ft (7.2 m), a width of 10.17 ft (3.1 m), and a height of 8.2 ft (2.5 m). It weighs approximately 44,000 lbs (20,000 kg) and has a maximum sheet size of 29.92 x 41.73 in (760 x 1060 mm). The machine's maximum printing speed is 18,000 sheets per hour.
Paper Handling : The Speedmaster XL 106 features a high-capacity feeder with a maximum pile height of 31.5 in (800 mm) and a sheet size range of 11.81 x 15.75 in (300 x 400 mm) to 29.92 x 41.73 in (760 x 1060 mm). The machine is equipped with a dual-circuit sheet guiding system and a high-precision sheet alignment system, ensuring accurate registration and smooth paper flow. The delivery system features a high-capacity stacker with a maximum pile height of 31.5 in (800 mm) and a sheet ejection system for easy sheet removal.
Printing Unit : The Speedmaster XL 106 features a high-performance printing unit with a maximum printing speed of 18,000 sheets per hour. The machine uses a combination of conventional and UV inks and is equipped with a high-precision plate cylinder with a diameter of 4.33 in (110 mm). The printing unit features a advanced dampening system, a high-precision inking system, and a sophisticated temperature control system, ensuring consistent and high-quality printing results.
Ink System : The Speedmaster XL 106 uses a high-performance ink system with a maximum ink flow rate of 12.34 oz/min (360 ml/min). The machine features a dual-ink fountain system with a maximum ink capacity of 26.4 gal (100 l) and is equipped with an advanced ink metering system, ensuring precise ink application and reduced ink waste.
Plate Cylinder : The Speedmaster XL 106 features a high-precision plate cylinder with a diameter of 4.33 in (110 mm) and a maximum plate size of 29.92 x 41.73 in (760 x 1060 mm). The plate cylinder is equipped with a advanced clamping system, ensuring precise plate registration and smooth plate movement. The machine features a high-performance plate changing system, allowing for fast and efficient plate changes.
