| Features | Value |
|---|---|
| Number of colours | 4 |
| Max sheet size | 40.2 x 28.3 inch | 102 x 72 cm |
Machine Description
HEIDELBERG SM 102 V.
Year 1990.
CPC 1.03.
Cp tronic.
Size 28x40.
Max paper size.
72x102cm.
Max print area* *70x102cm.
Max Speed per Hour:15000.
Four colour.
Auto Blanket wash .
Straight machine.
Quick plate clamp.
Alcolour dampening.
With Baldwin chillar.
Power spray.
Stream feeder.
All gears & cylinders in very excellent condition
| Model | Heidelberg-Speedmaster SM 102-4 |
|---|---|
| Manufacturer | Heidelberg |
| Year | 1990 |
| Machine Availability | Immediately from stock |
| Machine Condition | Rebuilt |
| Price | On Request |
| Location | Delhi NCR, Surajpur, Greater Noida, Uttar Pradesh, India |
Special Features
- Alcolor Dampening
- Computer Controls/ Digital Controls
- Dryer
About Heidelberg - Speedmaster SM 102-4
The Heidelberg Speedmaster SM 102-4 is a high-performance sheet-fed offset printing press designed for commercial and industrial printing applications. This machine is part of the Speedmaster series, known for its exceptional print quality, reliability, and versatility. The SM 102-4 is ideal for printing a wide range of materials, including paper, board, and plastics, and is commonly used in the production of brochures, catalogs, labels, and packaging materials. Its key features include high-speed printing, precise registration, and advanced automation, making it an excellent choice for high-volume printing operations.
Key Technical Aspects:
Dimensions and Specifications : The Heidelberg Speedmaster SM 102-4 has a length of 23.62 ft (7.2 m), a width of 6.56 ft (2 m), and a height of 7.38 ft (2.25 m). It weighs approximately 44,000 lbs (20,000 kg) and has a maximum sheet size of 28.35 x 40.16 in (720 x 1020 mm). The machine's maximum printing speed is 15,000 sheets per hour.
Paper Handling : The SM 102-4 features a high-capacity feeder with a maximum pile height of 31.5 in (800 mm) and a sheet size range of 12.6 x 18.1 in (320 x 460 mm) to 28.35 x 40.16 in (720 x 1020 mm). The machine is equipped with a double-sheet detection system and an anti-static device to prevent sheet sticking. The delivery system features a high-pile stacker with a maximum pile height of 31.5 in (800 mm) and a sheet ejection system for easy sheet removal.
Printing Unit : The Heidelberg Speedmaster SM 102-4 features four printing units, each with a maximum printing speed of 15,000 sheets per hour. The machine uses a conventional offset printing process with a maximum printing resolution of 2540 dpi. The printing units are equipped with advanced features such as automatic plate changing, automatic wash-up, and a dampening system for consistent ink transfer.
Ink System : The SM 102-4 uses a conventional offset ink system with a maximum ink capacity of 22.04 lbs (10 kg) per unit. The machine features an advanced ink train system with automatic ink supply and a built-in ink agitator for consistent ink flow.
Plate Cylinder : The plate cylinder on the Heidelberg Speedmaster SM 102-4 has a diameter of 4.33 in (110 mm) and a circumference of 13.58 in (345 mm). The plate cylinder is designed for high-speed printing and features an advanced clamping system for precise plate registration and consistent print quality.
