Heidelberg - CD102-5 L

Key Technical Aspects:

Dimensions and Specifications : The Heidelberg CD102-5 L has a length of 7,540 mm, a width of 2,440 mm, and a height of 2,240 mm. It weighs approximately 12,500 kg and has a maximum sheet size capacity of 720 x 1,020 mm.

Paper Handling : The CD102-5 L features a high-performance paper handling system, including a feeder with a capacity of up to 5,000 sheets, an in-line sheet inspection system, and a delivery system with a pile height of up to 1,500 mm. The machine can handle a wide range of paper weights, from 80 to 500 gsm.

Printing Unit : The printing unit of the CD102-5 L is equipped with five printing units, each capable of producing up to 15,000 sheets per hour at a maximum print speed of 15,000 sheets per hour. The machine features a maximum print resolution of 2,438 dpi and uses Heidelberg's proprietary Hi-Res Screen technology.

Ink System : The CD102-5 L uses a high-performance ink system with a capacity of up to 20 kg per color. The machine features a fully automatic ink supply system, ensuring consistent and accurate ink transfer. The ink system is designed for use with conventional offset inks.

Plate Cylinder : The plate cylinder of the CD102-5 L has a diameter of 1,020 mm and is designed for use with Heidelberg's proprietary Saphira plate technology. The plate cylinder features a fully automatic plate changing system, allowing for fast and efficient job changes.
