Shinohara - 52

Key Technical Aspects:

Dimensions and Specifications : The Shinohara 52 has a length of 5,500 mm, a width of 1,800 mm, and a height of 1,900 mm. It weighs approximately 4,500 kg and has a maximum printing speed of 15,000 sheets per hour. The press has a maximum sheet size of 520 x 740 mm and a minimum sheet size of 350 x 500 mm.

Paper Handling : The Shinohara 52 features a advanced paper handling system, including a high-capacity feeder with a maximum pile height of 1,200 mm and a sheet capacity of 5,000 sheets. The press is equipped with a double-sheet detection system and an anti-static device to prevent sheet sticking. The delivery system features a jogger and a stacker, with a maximum pile height of 1,000 mm.

Printing Unit : The Shinohara 52 has a maximum printing speed of 15,000 sheets per hour, with a print resolution of 300 lpi. The press uses a conventional offset printing process with a maximum printing area of 520 x 740 mm. The printing unit features a seven-color configuration, with a maximum ink transfer rate of 1.2 mm.

Ink System : The Shinohara 52 uses a conventional offset ink system, with a maximum ink capacity of 20 kg per color. The press features an automatic ink supply system, with a ink temperature control range of 20-30°C.

Plate Cylinder : The Shinohara 52 features a plate cylinder with a diameter of 520 mm and a circumference of 1,650 mm. The plate cylinder is designed for high-speed printing, with a maximum plate change time of 10 minutes.
