Machine Description
Horizon PF-40L .
.
Specification .
.
Paper Folder .
.
Sheet Feeding System Air rotor system .
.
Sheet Size (Width x Length) Max. 320 x 630 mm/ 12.59” x 24.80” .
.
- The fold pattern is limited depending on the sheet length and the stopper adjustable range. For a sheet 430 mmor longer, only sheets of up to 105 gsm can be folded. .
.
Min. 125 x 128 mm/ 4.93” x 5.04” .
.
A3 / B4 / A4 / B5 / 11” x 17” / 8.5” x 14” / 8.5” x 11” / 5.5” x 8.5” .
.
Sheet Weight Range Normal Paper: 52 to 157 gsm .
.
Coated Paper: 73 to 157 gsm .
.
Feeder Stack Height Max. 105 mm/ 4.13” .
.
Fold Patterns Single Fold, Double Parallel Fold, Short Fold, Accordion-Fold, Letter Fold, Open Gate Fold .
.
Production Speed 270 sheets per minutes (A3 single fold) .
.
390 sheets per minutes (A4 single fold)The PF-40L combines high-volume suction feed capabilities with the intelligent automation that Horizon products are so well known for. The 1,000 sheet capacity top-fed system is the same suction feed system as is used on both the highly popular VAC Collators and PF-P330 Folder providing for reliable mark-free feeding from static laden digitally printed sheets as well as conventional prints
| Model | Horizon-PF-40L |
|---|---|
| Manufacturer | Horizon |
| Machine Availability | Immediately from stock |
| Machine Condition | In Stock |
| Price | On Request |
| Location | Lancaster, United Kingdom |
About Horizon - PF-40L
The Horizon PF-40L is a high-performance, floor-model paper folder designed for heavy-duty use in commercial print shops, in-plant facilities, and high-volume document centers. This machine is ideal for folding large quantities of paper quickly and accurately, making it an essential tool for businesses that require efficient document processing. Key features of the Horizon PF-40L include its high-speed folding capability, advanced paper handling system, and user-friendly interface. The benefits of using this machine include increased productivity, reduced labor costs, and improved document quality. Typical applications of the Horizon PF-40L include folding invoices, statements, letters, and other business documents.
Key Technical Aspects:
Dimensions and Specifications : The Horizon PF-40L measures 73.6 inches in length, 43.3 inches in width, and 55.1 inches in height, with a weight of approximately 1,323 pounds. It has a maximum sheet size capacity of 14.33 inches x 20.47 inches and a minimum sheet size capacity of 5.51 inches x 7.87 inches.
Paper Handling : The Horizon PF-40L features a high-capacity paper handling system with a 500-sheet input tray and a 1,000-sheet output tray. It also has a built-in sheet alignment system and a jogger function for easy paper alignment and registration.
Folding Unit : The Horizon PF-40L has a high-speed folding unit that can produce up to 40,000 folds per hour. It features a 6-bucket folding system with adjustable fold plates and a precision-guided folding mechanism for accurate and consistent folds.
Control System : The Horizon PF-40L has a user-friendly control system with a 7-inch color touchscreen display and a simple, intuitive interface. It also features a built-in counter and a batch counter for easy job tracking and monitoring.
Optional Features : Optional features of the Horizon PF-40L include a slitter shaft, a perforation module, and a scoring module, which can be added to enhance the machine's functionality and versatility.
