Gutenberg - TC-800

Key Technical Aspects:

Dimensions and Specifications : The Gutenberg TC-800 has a length of 7,300 mm, a width of 2,300 mm, and a height of 2,200 mm. It weighs approximately 12,000 kg and has a maximum printing speed of 15,000 sheets per hour. The press has a maximum sheet size of 720 x 1,020 mm and a minimum sheet size of 350 x 500 mm.

Paper Handling : The TC-800 features a high-capacity paper handling system, including a feeder with a capacity of 5,000 sheets, an intermediate stacker with a capacity of 2,000 sheets, and a delivery stacker with a capacity of 3,000 sheets. The press is equipped with automatic sheet alignment, sheet detection, and anti-static devices to ensure smooth and efficient paper handling.

Printing Unit : The Gutenberg TC-800 is equipped with eight printing units, each featuring a maximum printing speed of 15,000 sheets per hour. The press uses a conventional offset printing process with a maximum resolution of 254 lpi. The printing units are equipped with automatic plate changers, ink fountain rollers, and impression cylinders to ensure high-quality printing and efficient production.

Ink System : The TC-800 uses a conventional ink system with eight ink zones, each with a capacity of 20 kg. The press is equipped with an automatic ink supply system, which ensures consistent ink flow and reduces waste. The ink system also features an ink temperature control system to maintain optimal printing conditions.

Plate Cylinder : The plate cylinder of the Gutenberg TC-800 has a diameter of 1,200 mm and a length of 720 mm. The plate cylinder is equipped with automatic plate changers, which allow for fast and efficient plate changes. The plate cylinder is designed to accommodate a wide range of plate materials, including aluminum, steel, and polyester.
